MSI MAG 850W Power Supply PSU

Information:

PCIE 5 Full Modular 80 Plus Gold Certified 850W Compact Size ATX PSU

Description:

SKU: 306-7ZP8A24-CE0
📍Description

▸ Type:  ATX12V V3.1
 ▸ Output Capacity:  850W
 ▸ Efficiency Rating:  80 PLUS Gold Certified
 ▸ Form Factor:  ATX
 ▸ Modularity:  Full Modular
 ▸ Compact Size:  150 x 140 x 86 mm

 ▸ Cooling System:
▸ 120mm FDB (Fluid Dynamic Bearing) Fan
▸ Intelligent Speed Control for Optimal Cooling

 ▸ High-Quality Components:
▸ Japanese Bulk Capacitor for Enhanced Reliability

 ▸ Performance & Stability:
▸ Efficiency ≥90% at 50% Load
▸ Hold Up Time ≥16ms (80% Load)
▸ Power Good Signal: 100-150ms
▸ MTBF: 100,000 Hours

 ▸ Safety & Protection:
▸ OPP (Over Power Protection)
▸ OVP (Over Voltage Protection)
▸ SCP (Short Circuit Protection)
▸ OTP (Over Temperature Protection)
▸ OCP (Over Current Protection)
▸ UVP (Under Voltage Protection)
▸ SIP (Surge & Inrush Protection)
▸ NLO (No Load Operation)

▸ Regulatory Compliance:
▸ CE, FCC, CCC, cTUVus, RCM, EAC, BIS, TUV-RH
▸ ErP 2014 Compliant

▸ Connectors:
▸ 1x 20+4-Pin ATX
▸ 2x 8-Pin (4+4) EPS CPU
▸ 3x 6+2-Pin PCIe
▸ 1x 16-Pin PCIe 5.0 (12V-2×6)
▸ 2x SATA + 1x 4-Pin Molex

A powerful and efficient PSU with a compact design, full modular cables, and stable power delivery for high-performance systems!
