MERCUSYS AC12 AC1200 Dual Band WiFi Router

Information:

💡 MERCUSYS AC12 AC1200 Dual-Band Wi-Fi Router | 4× 5dBi Antennas | 300 + 867 Mbps | Guest Network | IPTV & IPv6 | Easy 3-Step Setup | WPA2 Security

Description:

🎯  Features – High-Speed, Dual-Band Coverage
✔ Next-Gen AC1200 Wi-Fi – 300 Mbps on 2.4GHz + 867 Mbps on 5GHz for streaming, gaming, and HD video calls
✔ Dual-Band Simultaneous Connections – Reduces congestion and improves network stability across multiple devices
✔ Extended Range with 4× 5dBi Antennas – Strong signal and minimized dead zones for home or office
✔ 2×2 MIMO Technology – Handles multiple data streams for smoother performance with multiple users
✔ Guest Wi-Fi Network – Separate secure network for visitors without exposing your main network
✔ Full IPTV & IPv6 Support – IGMP Proxy/Snooping, VLAN, Bridge mode, and future-ready IPv6 compatibility
✔ Fast & Easy Setup – Simple 3-step web-based installation for anyone
✔ Smart Management Options – Remote/local management, access control, port forwarding, and diagnostics
✔ Advanced Wireless Security – WPA-PSK/WPA2-PSK, IP/MAC binding, and SPI firewall protection

⸻

📊  Specs – MERCUSYS AC12
▸ Model: MERCUSYS AC12
▸ Wi-Fi Standards: IEEE 802.11a/n/ac (5GHz), IEEE 802.11b/g/n (2.4GHz)
▸ Wi-Fi Speeds: 300 Mbps (2.4GHz), 867 Mbps (5GHz)
▸ Frequency Bands: 2.4–2.5 GHz, 5.15–5.25 GHz
▸ Antennas: 4× 5dBi External Fixed
▸ MIMO Technology: 2×2 MIMO
▸ Reception Sensitivity: 2.4GHz –95 to –71 dBm; 5GHz –92 to –60 dBm
▸ Security: WPA-PSK/WPA2-PSK, IP/MAC Binding, SPI Firewall
▸ Wireless Functions: Enable/Disable Radio, Wireless Statistics
▸ Guest Network: Separate on 2.4GHz & 5GHz
▸ WAN Port: 1× 10/100 Mbps
▸ LAN Ports: 3× 10/100 Mbps
▸ WAN Types: Dynamic IP, Static IP, PPPoE, L2TP, PPTP
▸ Port Forwarding: Virtual Server, UPnP, DMZ
▸ Management: Local, Remote, Access Control
▸ DHCP Server: Yes
▸ Setup Method: Web Interface (3-Step Installation)
▸ IPTV Support: IGMP Proxy/Snooping, VLAN, Bridge
▸ IPv6 Support: Yes
▸ Button: WPS / Reset
▸ Dimensions: 222 × 140 × 32 mm
▸ Power Supply: 9V / 0.85A External Adapter
▸ Color: Black

⸻

⚡ The MERCUSYS AC12 provides fast dual-band AC1200 Wi-Fi with strong coverage, guest networks, and easy setup—ideal for home or small office use.
